L'ammasso globulare M12 in Ofiuco

Ammasso globulare M12 in Ofiuco
(NGC 6218)
Globular clusters M12 in Ophiucus
(NGC 6218)
A.R. 16h47m12s - Decl. -01°57'00"
Crop al 200%
Questa foto dell'ammasso globulare M12 in Ofiuco è stata scattata il 11 giugno 2010 dal giardino di casa ad Arcidosso (GR) al fuoco diretto di un telescopio Takahashi TSA 102 ridotto a f/6.3 su montatura Gemini G41 Obs.
L'esposizione è la somma di 14 frames da 12 minuti ciascuno e di 8 da 90 secondi ripresi con la Canon EOS 40D settata a 800 ISO e modificata con Filtro Baader IR-Cut, ed è stata effettuata con autoguida Atik 16IC e rifrattore 120/600 in parallelo.
La temperatura esterna era di 17° ma con un prototipo di cold box da me realizzato ho operato a temperature di circa 10° più basse costantemente. Le stelle sono leggermente elongate a causa di raffiche di vendto che superavano i 5 m/s.
Successivamente i frames sono stati allineati calibrati con Deep Sky Stacker mediante l'uso di 19 dark da 12 minuti, 16 dark da 90 secondi, 21 flat, 21 dark dei flat e 21 bias, poi allineati e sommati con Registar, processati mediante applicazione di stretching, maschera sfocata, deconvoluzione, bilanciamento dei colori,  riduzione del rumore.
Nella tabella sottostante sono riportati i valori di temperatura, umidità e brillanza del cielo nella zona ripresa (usando lo SQM-L) a vari orari.
This photo of the globular clusters M12 in Ophiucus, was taken on june 11, 2010 from the backyard of my home in Arcidosso, in Italy, near Grosseto, at the prime focus of a Takahashi TSA102 telescope reduced at f/6.3 using a Gemini G41 Obs mount.
The photo is the sum of 14 frames of 12 minutes plus 8 frames of 90 seconds, taken using a Canon Eos 40D Digital camera, modified with a Baader IR-Cut filter, at 400 ISO and they were taken with an Atik 16IC autoguide on a small refractor 120/600.
The air temperature was about 65°F but. using a self made cold box my dslr worked at about 18°F less. Cause gusts more than 5 m/s I had the stars slightly elongated.
About processing.
I calibrated the frames with Deep Sky Stacker using 18 darks of 15 minutes each, 21 darks of 2 minutes each, 21 flats, 21 darks of flat, 21 bias.
Then I stacked and summed the resulting frames with Registar, and processed the resulting file with stretching, unsharp mask, deconvolution, color balance, noise reduction.
In the table below I put the value of temperature, humidity and brillance of the sky in the zone of the clusters (using a SQM-L) taken in different time.
ORA/TIME (U.T.) Temperatura dell'aria (Celsius) Temperatura della fotocamera (Celsius) Umidità SQM
21:05 18° C 8.3° C 75% 20.55
22:15 17° C 7.8° C 76% 20.63
22:45 17° C 7.5° C 75% 20.68
23:20 17° C  7.9° C 66% 20.82
00:20 17° C 8.4° C 73% 20.77
